16" X 60" GMC GML-1660HD Gap Bed Lathe w/DRO *New*

16" X 60" GMC GML-1660HD Gap Bed Lathe w/DRO *New*

Location:Ontario, CA

orCall (714) 545-0940

Equipped With

Equipped with:

  • SINO DRO (installed)
  • Taper turning attachment (installed)
  • 8” 3-jaw chuck with one set of reversible jaws
  • 10” 4-jaw chuck
  • 12” Face plate
  • 5 1/2” large steady rest with roller jaws (bearings)
  • Oil pump on Apron for all guideways and leadscrews
  • 2” follow rest with roller jaws (bearings)
  • Removeable gap
  • 4-way tools post
  • Foot brake
  • Halogen Work light and coolant system
  • Full length splash guard
  • (2) dead centers and (1) reducing sleeve MT6/MT4
  • Thread chasing dial
  • Tool box and leveling pads


Specifications

ManufacturerGMC Machine Tools
ModelGML-1660HD
ConditionUsed
Max Swing Over Bed16 1/16"
Max Workpiece Length60"
Max Swing Over Cross Slide10 1/4"
Bed Width10 1/4"
Spindle Bore2 1/16" D1-6
Spindle Speed45 - 1,800 RPM
Range of Longitudinal Feeds0.0018 - 0.07 IPR, 42 Kinds
Range of Cross feeds0.0009-0.03 IPR, 42 kinds
Main Motor6 HP, 220V/20A, 3 Phase
Coolant Pump1/8 HP, 220V, 3 Phase
Overall Dimensions (approx.)100" x 32.2" x 56"H
Weight (approx)4850 lbs.
