14 Ga. x 10' GMC HS-1014MD Hydraulic Shear
14 Ga. x 10' GMC HS-1014MD Hydraulic Shear
Location:Santa Ana, CA
orCall (714) 545-0940
Equipped With
Standard Features:
- Taiwan machines
- ISO 9001 certified
- HD all steel construction for maximum rigidity
- German logic quiet Rexroth hydraulic system
- Adjustable stroke from 16-20 strokes per minute
- 60” long squaring arm with inch / mm scale
- Spring hold-downs
- High grade carbon/chrome alloy steel blades and hardened to 62 hrc,
- 2-edge indexable upper blade and 2-edge indexable bottom blade
- Full length with full view finger guard
- Front supports and (2) side gauges
- Safety type foot pedal control
- Jog, single continuous auto operation modes
- One year warranty for parts
Standard Equipment:
- 26” manual back gauge with inch/metric dual scale & one side operated hand wheel
- 60” long squaring arm with inch / mm scale
- 2 each 24” front support arms
- 2 each 14” Side gauges with inlaid inch/metric dual scale
- Spring independent hold-downs
- Full length finger guard
- Removable safety foot
Specifications
| Manufacturer | GMC Machine Tools |
| Model | HS-1014MD |
| Condition | New |
| Stock Number | HS-1014MD |
| Product | Shears, Hydraulic |
| Overall Cutting Length | 120" |
| Maximum Cutting Capacity | Mild Steel 10’ x 14Ga. / Stainless Steel 10’ x 18 Ga / Soft Aluminum 10' x 10 Ga |
| Minimum Capacity | 26 Ga. |
| Blade Length | 10' 1" |
| Strokes Per Minute | 14-18 |
| Throat | 16" |
| Working Height | 30.5" |
| Front Support Arm | 24" |
| Back Gauge Range | 26" |
| Rake of Upper Blade | 1.5 degrees |
| Oil Tank Capacity | 20 Gallson |
| Main Motor | 5-1/2 HP 220V/440V, 3PHASEe (Optional: 440V 3-Phase) |
| Overall Dimensions | 139 x 35 x 52"H |
| Weight (approx.) | 5200 lbs. |
